Playing with the Fourier Transform

The beauty of the Fourier Transform never ceases to amaze me. And since several effects in ArionFX are based on it, I have had to play with it a lot in recent times.

As explained in a previous post, diffraction patterns (e.g., the glare simulated in ArionFX for Photoshop) come from the Fourier Transform of the lens aperture. I will use the FT of an aperture mask for visualization in this post.

I will use pow-2 square sizes (my FT implementation is an FFT). Let’s start by this Aperture x Obstacle map output directly from ArionFX for Photoshop v3.5.0.

Aperture x Obstacle mask, rasterized @ 512×512

The Fourier Transform of that image, rasterized at that size in said 512×512 buffer, is the following.

FT of the mask above

The faux-color is done on the magnitude of each complex number in the FT. All the FT images in this post are normalized equally, and offset to look “centered” around the mid-pixel.

Such diffraction patterns and some heavy convolution magic are what ArionFX uses to compute glare on HDR images:

Resulting glare in ArionFX

Now, let’s focus on what happens to the FT (frequency space) when one does certain operations on the source data (image space). Or, in this exemplification: what happens to the diffraction pattern, when one plays with the rasterized aperture mask.

Note that we’re speaking of the Discrete Fourier Transform, so sampling (rasterization, pixelization) issues are mostly ignored.

Rotation about the center

A rotation of the source buffer about its center doesn’t change the frequencies present in the data; only their orientation. So a rotation in the source data rotates the FT rotates in the exact same way.

As we will see next, this property holds true regardless of the center of rotation, because the FT is invariant with respect to translations.

Rotation about the center

Translation (with warp-around)

Frequencies arise from the relative position of values in the data field, and not from their absolute position in said field. For this reason, shifting (warp-around included) the source data does not affect the corresponding Fourier Transform in any way.

Invariance to translation

Let’s recall that the idea behind the FT is that “any periodic function can be rewritten as a weighted sum of sines and cosines of different frequencies”. Periodic being the keyword there.

Repetition (tiling)

Tiling the data buffer NxM times (e.g., 2×2 in the example below) produces the same FT, but with frequencies “exploded” every NxM cells, canceling out everywhere else.

This is because no new frequencies are introduced, since we are transforming the same source data. However, the source data is NxM times smaller proportional to the data buffer size (i.e., the frequencies become NxM times higher).

Exploded frequencies on tiling

Data scaling

Normalization and sampling issues aside, scaling the data within the source buffer scales the FT inversely.

This is because encoding smaller data requires higher frequencies, while encoding a larger version of the same data requires lower frequencies.

Inverse effect on scaling

In the particular case of glare (e.g., ArionFX) this means that the diffraction pattern becomes blurry if the iris is sampled small. Or, in other words, for a given iris, the sharpest diffraction pattern possible is achieved when the iris is sampled as large as the data buffer itself.

Note, however, that “large” here means “with respect to the data buffer”, being the size of the data buffer irrelevant as we will see next.

Filling of missing image pixels

Here’s what we could call a mean pyramid of the 512×512 Lena image. i.e., a sequence of progressive 1:2 downscalings, where each pixel in the i-th downscaled level is the average of the corresponding 4 pixels in the previous level. For people familiar with OpenGL and such, this is what happens when the mipmaps for a texture map are computed:

The 9+1 mipmap levels in the 512×512 Lena image

There are many smart, efficient, and relatively simple algorithms based on multi-resolution image pyramids. Modern GPUs can deal with upscaling and downscaling of RGB/A images at the speed of light, so usually such algorithms can be implemented at interactive or even real-time framerates. This paper here is a nice dissertion on the subject.

Here is the result of upscaling all the mip levels of the Lena image by doing progressive 2:1 bi-linear upscalings until the original resolution is reached:

Upscaled mipmap levels

Note the characteristic “blocky” (bi-linear) appearance, specially evident in the images of the second row.

Lately, I have been doing some experimentation with pixel extrapolation algorithms that “restore” the missing pixels in an incomplete image. After figuring out a couple of solutions of my own, I found the paper above, which explains pretty much what my algorithm had become at that point.

The pixel extrapolation algorithm works in 2 stages:

1- The first stage (analysis) prepares the mean pyramid of the source image by doing progressive 1:2 downscalings. Only the meaningful (not-a-hole) pixels in each 2×2 packet are averaged down. If a 2×2 packet does not have any meaningful pixels, a hole is passed to the next (lower) level.

2- The second stage (synthesis) starts at the smallest level and goes up, leaving meaningful pixels intact, while replacing holes by upscaled data from the previous (lower) level.

Mean pyramid (with holes)

Note that the analysis stage can stop as soon as a mip level doesn’t have any holes.

Here is the full algorithm, successfully filling the missing pixels in the image.

Mean pyramid (filled)


This algorithm can be implemented in an extremely efficient fashion on the GPU, and allows for fantastic parallelization on the CPU as well. The locality of color/intensity is preserved reasonably well, although holes become smears of color “too easily”.

A small (classic) inconvenience is that the source image must be pre-padded to a power-of-2 size for the progressive 1:2 downscalings to be well defined. I picked an image that is a power-of-2 in size already in the above examples.

So: given the ease of implementation and the extreme potential in terms of efficiency, the results are decent, but there is some room for improvement in terms of detail preservation.

Scrambled Halton

The Halton sequence, which is one of my favourite algorithms ever, can be used for efficient stratified multi-dimensional sampling. Some references:

Van der Corput sequence
Halton sequence

It is possible to do stratified sampling of hyper-points in the s-dimensional unit hyper-cube by picking one consecutive dimension of the Halton series for each component. A convenient way to do so is to use the first s prime numbers as the basis for each Halton sequence.

It is well-known, however, that while this approach works great for low dimensions, high dimensions often exhibit a great degree of undesired correlation. The following image displays a grid where each cell combines two components of the 32-dimensional Halton hyper-cube.

Raw 32-dimensional Halton hyper-cube

One can easily spot how some pairs exhibit an obvious pattern, while others fill their corresponding 2D area very densely. This happens more aggressively for higher dimensions (i.e., to the right/bottom in the image) and for pairs formed with close components (i.e., near the diagonal in the image). Click to enlarge!

A successful approach to dissolve this problem without losing the good properties of stratification is to do “random digit scrambling” (a.k.a. rds). During the construction of a Halton number, digits in the range [0..base[ are combined. Given a Pseudo-Random Permutation of length=base, all that one must do is use PRP(digit) instead of digit directly. This somewhat shuffles Halton pairs in rows and columns in a strong way so the correlation disappears. However, since the PRP is a bijection, the good properties of stratification are generally preserved.

How to build a strong and efficient randomised PRP of an arbitrary length is an interesting subject which details I won’t get into here.

Here’s the scrambling strategy in action:

Scrambled 32-dimensional Halton hyper-cube

Now all the blocks in the grid look equally dense. Magic!

As long as one picks good PRPs, it is possible to generate any number of different samplings, all with the same good properties.

Uniform vs. stratified

This is a classic subject in numerical (Monte Carlo) integration.

Uniform 2D distribution vs. Halton series for the first 2 dimensions

To the left: 32768 points in a 512×512 image using a uniform random number generator (Mersenne Twister). To the right, the first 32768 pairs in the Halton series, using dimensions #0 and #1. Click to enlarge!

Hosek & Wilkie sky model

I have spent the past hours working on the sky model in Arion. This time, I am taking the Hosek & Wilkie model for a spin, as an alternative to our good old implementation of the Preetham sky model:

Preetham et al. sky model

Hosek & Wilkie sky model
